M8 Galvanised DIN 580 Eye Bolt with 140kg WLL / SWL

M8 Galvanised DIN 580 Eye Bolt with 140kg WLL / SWL

M8 galvanised DIN 580 eye bolt is designed to create a secure threaded lifting, fixing, or attachment point where a rated eye bolt pattern is required.

Manufactured in line with DIN 580, this eye bolt features an M8 threaded shaft and circular eye for connecting hooks, shackles, wire rope, chain, or other compatible fittings. The galvanised zinc coating provides improved corrosion resistance compared to plain steel.

This M8 size offers a higher working load than M6, making it suitable for general workshop use, machinery attachment points, trailers, containers, support points, and practical fixing tasks where the correct rated component is required.

Key Features

• Metric size: M8
• Standard: DIN 580
• Thread pitch: 1.25mm
• Working Load Limit / Safe Working Load: 140kg
• Galvanised steel construction
• Threaded shaft with circular lifting eye

Common Applications

• Light to medium lifting and attachment points
• Machinery, trailers, and containers
• Workshop and maintenance use
• Wire rope, chain, hook, and shackle connections

Important: Always check that the selected size, fixing method, thread engagement, and load direction are suitable for your application. Do not exceed the stated WLL / SWL.
