M10 Galvanised DIN 580 Eye Bolt with 230kg WLL / SWL

M10 Galvanised DIN 580 Eye Bolt with 230kg WLL / SWL

M10 galvanised DIN 580 eye bolt is designed to create a secure threaded lifting, fixing, or attachment point where a rated eye bolt pattern is required.

Manufactured in line with DIN 580, this eye bolt features an M10 threaded shaft and circular eye for connecting hooks, shackles, wire rope, chain, or other compatible fittings. The galvanised zinc coating provides improved corrosion resistance compared to plain steel.

This M10 size offers a higher working load than M8, making it suitable for machinery attachment points, trailers, containers, workshop use, maintenance tasks, and secure fixing applications where the correct rated component is required.

Key Features

• Metric size: M10
• Standard: DIN 580
• Thread pitch: 1.5mm
• Working Load Limit / Safe Working Load: 230kg
• Galvanised steel construction
• Threaded shaft with circular lifting eye

Common Applications

• Medium-duty lifting and attachment points
• Machinery, trailers, and containers
• Workshop and maintenance use
• Wire rope, chain, hook, and shackle connections

Important: Always check that the selected size, fixing method, thread engagement, and load direction are suitable for your application. Do not exceed the stated WLL / SWL.

See more in eye bolts or browse turnbuckles.
